MODEL A
Y1, Y2, X + ( R MANUEL)
AXIS CONFIGURATION
AXIS CONFIGURATION
Cnc Hydraulic Press Brake
- Axes configurations, Model A press brake can configure 3 axes (Y1, Y2, X) and maximum 4 axes (Y1, Y2, X, R)
- Model A controller is standard numerically ESA625
- Delem DA-52’S, Delem DA-53T or 2D graphical based controller ESA630, Cybelec
- Touch 8, Cybelec Touch 12 or Delem DA58T preferable optionally also.
- Frame steel constructions manufacturing certificated raw material has been designed according optimal and minimum deflections resistance criteria of design and analyses requirement
- Steel constructions productions by modern and advanced CNC machining center.
- Hydraulic cylinders, manufactured as precision from solid
- full material in ALPMAC facilities and made honed.
- Hydraulic pistons, manufactured from forged steel, hardened, grinding is done, and chrome-coated in ALPMAC facilities.
- Hydraulic block and valve made in Germany, originally, high level type for performance and stability.
- ALPMAC press brake have special hydralic pump have high effiency condition of low and high pressure range
- Low electricity consumptions concept with special hydraulic design and components
- Automatically reference
- Pressing force tonnage automatically calculated according material thickness, tools and checking tools damage and machine safety
- Stroke adjustment, retract features automatically
- Programmable bending fast down and return speed with slow up functions
- Save and recall bending programs, and searching different criteria tools material
- 2 working mode, full automatically and manual
- C frame shape linear scale holders for body deflections compensations, and protected cross working
- Overload alarm system electronically
- Hydraulic maximum limit protect system
- with safety valve group
- Calculations unfolded length, automatically and programmable bend order features, according to the material thickness, material type, tools features
- WILA type manual or motorized crowning systems with opposing wave optionally
3 axes: Y1, Y2, X + (R manual) axis
Stroke 160 mm up to 210mm
Throat 250 mm
CNC controller ESA625
Offline software
Quick clamping promecam type top tool system
Special high effiency pump for low electrical consumption
Original Hoerbiger or Bosch Rexroth complete sealed up hydraulic systems Germany produced with CE norms compatible
Schneider- Siemens etc. electrical components, with ventilations electrical cabinet
Stand type multi-functions control panel and foot pedal with CE norms compatible
Accurate, high accuracy, +- 0,005 mm linear scale
(Up to) 120 mm/second upper beam approach speed
(Up to) 80mm /second upper beam return speed
Heavy duty robust, cnc controlled back gauge guided with ball shaft and slide
Complete electrical switch board and control panel for 400V AC 3 phase 50Hz
Precision +-0,03mm servo motorised,
Backgauge system with driver
X axis stroke 750 mm
Back gauge speed 350mm /second
Movable back gauge fingers along of bending length by manually
Protect covers at the side
Top tool clamping Promecam system
Top tools hardened, grinded standard 835mm lengths, 66,6mm (1260)-105mm (1281) ( 400 ton and over ) high
Bottom tools hardened, grinded standard 835 mm lengths, 60x60mm, 4 channels 16/22/35/50 mm (2067)
Narrow table or wide table with T slot
CE conformity light guard rear of press category 4
Stroke 160 mm up to 210mm
Throat 250 mm
CNC controller ESA625
Offline software
Quick clamping promecam type top tool system
Special high effiency pump for low electrical consumption
Original Hoerbiger or Bosch Rexroth complete sealed up hydraulic systems Germany produced with CE norms compatible
Schneider- Siemens etc. electrical components, with ventilations electrical cabinet
Stand type multi-functions control panel and foot pedal with CE norms compatible
Accurate, high accuracy, +- 0,005 mm linear scale
(Up to) 120 mm/second upper beam approach speed
(Up to) 80mm /second upper beam return speed
Heavy duty robust, cnc controlled back gauge guided with ball shaft and slide
Complete electrical switch board and control panel for 400V AC 3 phase 50Hz
Precision +-0,03mm servo motorised,
Backgauge system with driver
X axis stroke 750 mm
Back gauge speed 350mm /second
Movable back gauge fingers along of bending length by manually
Protect covers at the side
Top tool clamping Promecam system
Top tools hardened, grinded standard 835mm lengths, 66,6mm (1260)-105mm (1281) ( 400 ton and over ) high
Bottom tools hardened, grinded standard 835 mm lengths, 60x60mm, 4 channels 16/22/35/50 mm (2067)
Narrow table or wide table with T slot
CE conformity light guard rear of press category 4
Delem DA52’s or Delem 53T CNC numerical control unit
ESA630, 2D graphical colored CNC control unit
(automatic search bend order, optimizations
collision check ), 7 inch, LCD, graphical colored
Cybelec Touch 8, 2D Graphic Touch Screen 8” manual bend
order calculations 4 axes with offline software PC1200
Cybelec Touch 12, 2D Graphic Touch Screen 12” automatic
bend order calculations 4 axes with offline software PC1200
Delem DA-58T – 2D Graphical CNC control
unit with offline software profile TL
WILA typ ‘opposing wave’ manual Crowning
(Anti-deflections) System
WILA typ ‘opposing wave’ motorized
crowning (anti-deflections) system
X+R 2 axis back gauge
Longer X axis range (stroke) 1000mm
DFS laser beams finger protections in front NON CE
CE conformity with AKAS Laser finger
protections manual and safety PLC
CE conformity with AKAS Laser finger protections motorized and safety PLC
CE Conformity with DSP finger protections manual and safety PLC
Light barriers in front ( for tandem applications )
220-240V 60Hz and 440V-480V 60 Hz double
operating voltage (by preliminary preparation)
Additional extra back gauge fingers
Additional extra front support arms
WILA type hydraulic or mechanic top tool clamping system
WILA type hydraulic or mechanic
bottom tool clamping system
Hydraulic Promecam type top tool clamping system
American type compatible top tool clamping system
Special stroke, special throat according requirements
Extra control panel foot pedal
T slot on table
Heat exchanger (oil cooler) by air or by chiller
Oil heating unit
Special Color
ROL1 or ROL2- ROL4 top tool clamping systems
220-240V 60hz operating voltage
440-480V 60hz operating voltage
ESA630, 2D graphical colored CNC control unit
(automatic search bend order, optimizations
collision check ), 7 inch, LCD, graphical colored
Cybelec Touch 8, 2D Graphic Touch Screen 8” manual bend
order calculations 4 axes with offline software PC1200
Cybelec Touch 12, 2D Graphic Touch Screen 12” automatic
bend order calculations 4 axes with offline software PC1200
Delem DA-58T – 2D Graphical CNC control
unit with offline software profile TL
WILA typ ‘opposing wave’ manual Crowning
(Anti-deflections) System
WILA typ ‘opposing wave’ motorized
crowning (anti-deflections) system
X+R 2 axis back gauge
Longer X axis range (stroke) 1000mm
DFS laser beams finger protections in front NON CE
CE conformity with AKAS Laser finger
protections manual and safety PLC
CE conformity with AKAS Laser finger protections motorized and safety PLC
CE Conformity with DSP finger protections manual and safety PLC
Light barriers in front ( for tandem applications )
220-240V 60Hz and 440V-480V 60 Hz double
operating voltage (by preliminary preparation)
Additional extra back gauge fingers
Additional extra front support arms
WILA type hydraulic or mechanic top tool clamping system
WILA type hydraulic or mechanic
bottom tool clamping system
Hydraulic Promecam type top tool clamping system
American type compatible top tool clamping system
Special stroke, special throat according requirements
Extra control panel foot pedal
T slot on table
Heat exchanger (oil cooler) by air or by chiller
Oil heating unit
Special Color
ROL1 or ROL2- ROL4 top tool clamping systems
220-240V 60hz operating voltage
440-480V 60hz operating voltage
